Zebra TC20 Mobile Computer

Dimensions

TC20 ALL-TOUCH:
5.27 in. L x 2.82 in. W x .63 in. D
134 mm L x 73.1 mm W x 16 mm D

TC20 WITH KEYBOARD:
6.45 in. L x 2.82 in W x .63 in. D
164 mm L x 73.1 mm W x 16 mm D

Weight

TC20 ALL-TOUCH: 6.88 oz./195 g
TC20 WITH KEYBOARD: 7.58 oz./215 g

Display

4.3 in. color WVGA (800x480); LED backlight; Corning Gorilla Glass

Imager Window

Corning Gorilla Glass

Touch Panel

Capacitive Touch Panel; multi-touch

Power

Non-removable
Rechargeable Li-Ion: standard capacity, 3000mAh
Charge in under 4 hours (10hrs = 1 Shift)
RTC backup

Expansion Shot

One 128GB micro SD slot

Network Connections

One USB OTG - host/client
(Type C connector)

Notifications

Unsolicited packet data and programmable

Keypad

TC20 All-Touch: On-screen Keypad
TC20 Keyboard: Numeric

Voice

PTT Pro, PTT Express

Audio

Speaker - 1 Watt (94dBA)
Voice support (Internal speaker/microphone)
2 microphones
Audio jack

Buttons

Scan on each side, Volume Up/Down, Power, push-to-talk (PTT) Key

CPU

QCOM MSM8937® 64-bit 8-Core, ARM® Cortex A53 1.4GHz, 512KB L2 cache, power-optimization

Operation System

Android Oreo 8.1

Memory

2GB RAM/16 GB Flash memory

Security

Verified Boot

Operating Temperature

14° F to 122° F / -10° C to 50° C

Storage Temperature

-40° F to 158° F / -40° C to 70° C

Drop Specifications

Multiple 4 ft./1.2 m drop to tile over concrete per MIL-STD at room temperature

Tumble Specifications

300 tumbles, 1.6 ft./0.5m

Sealing

IP65

Vibration

4G peak, 5 Hz to 2 kHz, 1 hour duration per axis

Thermal Shock

-40°C to 70°C rapid transition
10 cycles (1 cycle = 1.25 hours at -40°C and 1.25 hours at 70°C)

Electrostatic Discharge (ESD)

+/-15kv Air, +/-8kv contact, +/-8kv charge body

Accelerometer (3-axis), ambient light sensor, proximity sensor

Scanning

SE2100 1D/2D imager
SE4710 1D/2D imager + rear camera

Rear Camera

8MP autofocus color camera with flash

RFID

RFD2000 UHF RFID snap-on sled

WLAN Radio

802.11 a/b/g/n/ac/d/r/h/i IPv4, IPv6

Data Rates

2.4 GHz: 20 MHz, 40 MHz
5 GHz: 20 MHz, 40 MHz, 80 MHz

Operating Channels

2.4 GHz (channels 1-13; 1-11(US))
5GHz (channels 36-48, 52-64, 100-144, 149-165)
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency.

Security and Encryption

WPA/WPA2 (PSK & Enterprise 802.1x); EAPTTLS;
PEAPv0-MSCHAPv2; EAP-TLS

Certifications

802.11a/b/g/n; WPA; WPA2

Fast Roam

802.11r

Bluetooth

Bluetooth 4.2 BLE
